TK68HC05J1A Microcontroller

General Description

The TK68HC05J1A is a member of the low-cost, high-performance TK68HC05 Family of 8-bit microcontroller units (MCU). The TK68HC05 Family is based on the customer-specified integrated circuit (CSIC) design strategy. All MCUs in the family use the popular TK68HC05 central processor unit (CPU) and are available with a variety of subsystems, memory sizes and types, and package types.

On-chip memory of the TK68HC05J1A includes:

1240 bytes of user read-only memory (ROM)
64 bytes of user random-access memory (RAM)

Information on the TK68HCL05J1A, a low-power version of the TK68HC05J1A, is introduced in Appendix A. MC68HCL05J1A of the TK68HC05J1A Family Technical Data Sheet.

Information on the TK68HSC05J1A, a high-speed version of the TK68HC05J1A, is introduced in Appendix B. TK68HSC05J1A of the TK68HC05J1A Family Technical Data Sheet.

Features

Popular TK68HC05 CPU
Memory-mapped input/output (I/O) registers
1240 bytes of user ROM including eight user vector locations
64 bytes of user RAM
14 bidirectional I/O pins with these features:
- Software programmable pulldown devices
- Four I/O pins with 8-mA current sinking capability
- Four I/O pins with maskable external interrupt capability
Hardware mask and flag for external interrupts
Fully static operation with no minimum clock speed
On-chip oscillator with connections for a crystal or ceramic
resonator or for a resistor-capacitor (RC) network
15-bit multifunction timer
Computer operating properly (COP) watchdog
Power-saving stop (or halt), wait, and data-retention modes
Illegal address reset
Internal steering diode between RESET and VDD pins
8 × 8 unsigned multiply instruction
20-pin plastic dual in-line package (PDIP)
20-pin small outline integrated circuit package (SOIC)

Request for Product Information

To request information on our TK68HC05J1A Microcontroller click this button:

Request Information

Minimum Order Quantity

We will continue to sell the TK68HC05J1A parts with a MOQ of 100 units as long as we have inventory in stock. Once that inventory is gone, then minimum order quantities will increase to 5000 parts per order.
