TK68HC711KS2 Microcontroller



General Description

TK68HC11K Family devices feature up to 62 input/output (I/O) lines distributed among eight ports, A through H. The KS Family removes seven pins from port G and four pins from port H for a total of 51 I/O lines. The KSx versions are derived from the KAx version and feature a slow mode for the clocks to allow power conservation. Table 1-1 lists devices currently available in the K Family along with their distinguishing features.

NOTE:    Tekmos no longer offers the KA2 and KA4 devices. These devices have been replaced by the pin-for-pin compatible KS2.





Table 1-1. TK68HC11K Family Devices

Device Number

ROM or EPROM (Bytes)

RAM (Bytes)

EEPROM (Bytes)

I/O (Bytes)

Chip Select

Slow Mode

Packages

TK68HC(L)11K0
TK68HC(L)11K1
TK68HC(L)11K3 TK68HC(L)11K4

0
0
24 K
24 K

768
768
768
768

0
640
0
640

37
37
62
62

Yes
Yes
Yes
Yes

No
No
No
No


84-pin PLCC(1)
80-pin QFP(2)


TK68HC711K4


24 K


768


640


62


yes

no

84-pin CLCC(3)
84-pin PLCC
80-pin QFP

TK68HC11KS2
TK68HC11KS8

32 K
48 K

1K
1.5 K

640
640

51
51

No
No

Yes
Yes

68-pin PLCC
68-pin PLCC and 80-pin TQFP(4)

TK68HC711KS2
TK68HC711KS8

32 K
48 K

1K
1.5 K

640
640

51
51

No
No

Yes
Yes

68-pin CLCC
68-pin PLCC and 80-pin TQFP

1. PLCC = Plastic leaded chip carrier
2. QFP = Quad flat pack

3. CLCC = Ceramic leaded chip carrier
4. TQFP = Thin quad flat pack



Features

TK68HC711KS2 is a member of the TK68HC11K Family.  Features include:

  • 8-bit opcodes and data
  • 16-bit addressing
  • Two 8-bit accumulators, which can be concatenated to form one 16-bit accumulator
  • On-board memory:
    • 32 Kbytes or 48 Kbytes of ROM, EPROM, or OTPROM
    • 768 bytes, 1 Kbyte, or 1.5 Kbytes of static RAM (random-access memory)
    • 640 bytes of EEPROM
    • 128-byte register block
  • Dual-function I/O lines
    • Any pins used for the microcontroller's peripheral functions can be configured as general-purpose I/O lines
  • 68HC11K4 offers:
    • 1 Mbyte of address space, using on-chip memory mapping logic
    • Four programmable chip selects (expanded modes)
  • 16-bit timer system:
    • Three input capture (IC) channels, record event timing by storing the value of the timing system's 16-bit free-running counter when an input signal transition occurs
    • Four output compare (OC) channels, provide timed outputs by signaling when the free-running counter reaches a predetermined number
    • One IC or OC channel (software selectable)
  • 8-bit pulse accumulator
  • Four 8-bit pulse-width modulation (PWM) outputs
  • Enhanced asynchronous serial communications interface (SCI)
  • Enhanced synchronous serial peripheral interface (SPI)
  • 8-channel, 8-bit, analog-to-digital (A/D) converter
  • Computer operating properly (COP) watchdog system to guard against infinite loops and other system problems
  • Real-time interrupt timer



Request for Product Information

To request information on our TK68HC711KS2 Microcontroller click this button:



Minimum Order Quantity

We will continue to sell the TK68HC711KS2 parts with a MOQ of 100 units as long as we have inventory in stock. Once that inventory is gone, then minimum order quantities will increase to 3000 parts per order.
