TK68HC811E2 Microcontroller

General Description

The TK68HC811E2 is a member of the TK68HC11E family of MCUs. The full set of specifications can be found in the datasheet TK68HC11E. The operation of the entire family is largely the same except for the various configurations of RAM, ROM, or EPROM.

The Tekmos TK68HC811E2 is available in a 175ºC version.

The TK68HC811E2 is a fully static design using high-density complementary metal-oxide semiconductor (HCMOS) fabrication process that allows it to operate at frequencies from 2 MHz to dc, with very low power consumption.

The device is available in the 48 pin Ceramic DIP, the 52-pin PLCC, and the 52 pin PQFP packages.

Features

175ºC Operation
Enhanced screening for longer data retention
68HC11 Central Processing Unit (CPU)
Power Saving STOP and WAIT Modes
512 Bytes of On-Chip RAM, Data Retained During Standby
2048 Bytes Electrically Erasable Programmable ROM (EEPROM)
Asynchronous Non-Return to Zero (NRZ), Communications Interface (SCI)
Synchronous Serial Peripheral Interface (SPI)
8-Channel 8-Bit Analog-to-Digital (A/D) Converter
16-Bit Timer System
- Three Input Capture (IC) Channels
- Four Output Compare (OC) Channels
- One Additional Channel, Selectable as Fourth IC or Fifth OC
8-Bit Pulse Accumulator
Real-Time Interrupt Circuit
Computer Operating Properly (COP) Watchdog System
38 General-Purpose Input / Output (I/O) Pins
- 16 Bidirectional I/O Pins
- 11 Input-Only Pins
- 11 Output-Only Pins
48-Pin Ceramic Dual In-Line Package (DIP)
Pin for pin replacement of the NXP MC68HC811E2
