TK68HC705B32 Microcontroller

General Description

The TK68HC705B is a derivative of the HC05 microcontroller architecture. With a rich set of RAM, ROM, and EEPROM memory and a full set of peripherals, the TK68HC705B is well suited to a variety of controller tasks. These parts have been designed to be drop-in replacements for the NXP MC68HC705B16 or MC68HC705B32, with identical code execution, pin compatibility, and equivalent timing.

Features

Available in either the 16K or 32K flash memory sizes

Pin compatible, timing compatible replacement for the industry standard 68HC05 family CPU
Fully static design supports operation from 0 to 4.2 MHz at 5 volts and 2 MHz at 3 volts
Embedded memory with:
- 176 bytes of RAM
- 16K or 32K bytes of user Flash
- 256 bytes of byte erasable EEPROM
- Security bit for 224 bytes of EEPROM
Advanced peripherals including:
- Three 8-bit parallel I/O ports
- One 8-bit input-only port
- 16-bit timer with 2 input captures and 2 output compares
- 8-channel, 8-bit A/D converter
- UART (SCI) with independent baud rate selection and receiver wake up function
- Watchdog timer
- 5 Interrupt sources
- 2 PLM systems for D/A use
Self test / bootstrap mode
Multiple power saving modes
On chip crystal oscillator with divide by 2 or divide by 32 modes
Optional E-Clock output
Available in 52-pin PLCC package
-40 to +85°C operating temperature
Direct replacement for NXP MC68HC705B16 and MC68HC705B32 microcontrollers

Request for Product Information

To request information on our TK68HC705B32 Microcontroller click this button:

Request Information

Minimum Order Quantity

We will continue to sell the TK68HC705B32 parts with a MOQ of 100 units as long as we have inventory in stock. Once that inventory is gone, then minimum order quantities will increase to 3000 parts per order.
